This is a Prototype Product
Your feedback matters! This Lock Strike Jig is currently in the prototype stage. The more interest and feedback we receive from the carpentry community, the more likely we are to fully develop and manufacture this tool. Share your thoughts below and let us know if this would be valuable for your work!
See the Lock Strike Jig in Action
About the Lock Strike Jig
The Reptile Jigs Lock Strike Jig is a professional-grade tool designed to simplify the precise installation of locks and striking plates in doors. With its adjustable features and meticulous indicators, this jig ensures accurate and seamless results for doors of various thicknesses.
This jig is specifically designed to accommodate doors with thicknesses of 35mm, 40mm, 45mm, and 55mm. It comes complete with four high-quality plates that can be obtained from our shop. These plates are carefully crafted in two pairs: one pair for the lock side within the door, and the other pair for the striking plate side within the door lining.
Each plate features clear and precise indicators, providing guidance for the correct depths of the router plunge cut. The plates also include reference numbers and essential information related to part 1 or part 2. With this jig, you can achieve consistent and professional results, even when working with different door thicknesses.
Key Features & Benefits
- Multiple Door Sizes: Works with 35mm, 40mm, 45mm, and 55mm doors
- Complete Set: Includes 4 precision plates (2 pairs)
- Clear Indicators: Depth guides for perfect router cuts
- Professional Results: Consistent, accurate installations
- Easy Ordering: Intuitive online form with visual aids
- Secure Attachment: Optional clamp system (no screw holes)
- Router Guide Block: Sets router to exact depths
- Minimal Chiseling: Part 2 plates reduce manual work
- Versatile Design: Works for locks and striking plates
- Affordable: Just £15 per complete lock set
How to Use
- Attach the jig to the door or lining using 15mm screws (or optional clamps)
- Insert the appropriate plate for your door thickness
- Set your router to the correct depth using the plunge router guide block
- Cut out the areas indicated by the plate markers
- Repeat the process with part 2 of the plates
- Use a chisel to square off internal corners if necessary (minimal work required)
- Install your lock and striking plate for a perfect fit
Installation Options
Screw Attachment: For standard installations, secure the jig using a couple of 15mm screws. This provides a stable and reliable setup for accurate routing.
Clamp Attachment: For doors that will be painted or when a seamless finish is required, the jig is equipped with optional attachments that allow you to clamp it to the door. This eliminates visible screw holes and provides a clean, professional appearance.
Router Guide Block: Available as an extra from our shop, this accessory enables you to easily and accurately set your router to the desired depths, ensuring precise and consistent cuts during the installation process.
Product Gallery
Lock Strike Jig
Lock Strike Jig
Ordering Custom Plates
When ordering the plates, the process is both intuitive and efficient. Simply provide measurements of your locks and striking plates using our online form's visual aids, diagrams, and images. This ensures accurate measurements and a seamless ordering experience.
The plates are affordably priced at just £15 per lock set, which includes all four plates (2 for the lock side, 2 for the striking plate side).
